1. Material |
304stainless steel, thickness:1.5mm(full thickness) |
|
2. Dimension |
L168*H1050mm |
|
3. Channel width |
≥600mm |
|
4. arm material |
transparent acrylic optional |
|
5. Drive motor |
brushless DC motor. |
|
6. Environmental requirements |
waterproof model, which can be used indoors and outdoors(canopy). |
|
7.Communication Interface |
RS485, Dry contact |
|
8.Passage Direction |
Single directional/Bi-directional |
|
9. Motor |
DC brush, rebound in case of resistance. |
|
10. Power of the whole machine |
50W. |
|
9. Traffic speed |
≥ 30 people per minute |
|
11.Opening mode support |
swiping card, QR code, ESD, fingerprint, face recognition,etc. |
Product feature
1.Support multiple pairs of sensors for real-time monitoring of channel status and accurate logic judgment.
Break, unhindered authorized passage.
2.Support: people, people carry backpacks to use.
3.NC machining technology:fine surface treatment, strong corrosion resistance.
4.Easy to use, easy to pass through personal belongings such as parcels, luggage, etc.
5.Mode of passage: one-way, two-way (optional).
6.Running speed: 0.4-1.2s (user-configurable).
7.Working mode: normally open / normally closed.
8.LED Light : status and traffic direction indication.
9.Protection function: with anti-clamping, anti-collision, anti-electrical over-voltage and over-current functions.
10. With IP45 protection grade, it can be well used indoors and outdoors.
1. Professional technical team.
2. Quick response.Technical support for maintenance by telephone, email, on-line etc all the life.
3. Optional shipping terms:EXW,FOB,DDU,DDP etc.
Q. How about the quality of your products?
A:We are in the highest level of quality with the most competitive price. At factory, we implement 5S management to control production process.
Q. How do you do after-sale service?
A:We provide life-time technology support on line, by emails, video, phone etc , convenient to communicate with you directly.
Q. How about the lead time?
A:Normally we have stock for the hot sale models of standard products.Regular products need 3-5 working days. The customized products need 5-10 working days.
Q. How long is your warranty period?
A:One-year guarantee & Life-time technology support.
Q. How about your package?
A:Seaworthy wooden case + Foam.
If you have any questions, please contact us .we will provide our best service.Look forward to our cooperation,thanks.
